The Overloader2 is a high performance computerized battery maintenance system. Capable of charging, discharging, cycling and conditioning multiple rechargable battery types, with very high output power, a customized display with expertly designed software and programming controls.
Features
Perfect for electric cars, trucks, boats and planes
1-12 cells charging & discharging (for Glowstarter & Batteries for planes)
Handling NiCd / NiMH / Li-Po / PB / Lixx battery types
Graphical display show charge, discharge and cycle curves
Storing up to 10 different battery configurations
Performs 1 - 10 cycles for NiCd / NiMH only, and stores capacity and voltage date
Break-in electric motors or operate commutator lathes
Heat glow plugs for nitro engines
Operate tire warmers
Adjustable language (English, German, French)
Restart of charge and discharge after a loss of power
Intelligent cooling fan control system for better charge efficiency
LCD contrast, fan operation, temp scale and sound cues are fully adjustable
Popups for information and warnings

Specification
Case: Aluminium, red anodized
Case Size: 176x134.7x52.9mm
Weight: 720g
Cooling System: 3x Fan 40x40mm
Input type: Input cable w/banana plugs red/black
Output type: Banana jacks black/red
Input voltage: 11-15V
Battery types: NiCd, NiMH, LiPo, Lixx, Pb
Battery Memories: 10
Language: English, German, French
Finish sound: 9
Specific for NiMH/NiCd
Charge mode: Linear, Impulse, Reflex, Auto, 4-Step
Cells: 1-12
deltaPeak/cell: 1-30mV
Peak-Lock time: 1-50min
Trickle current: Off, 10-400mA
Limits of discharge current: 1-6 cells - max 20,0A
Cutoff voltage/cell: 0,5-1,2V
Cycle mode: Off, L->E, E->L, (E)L->E
Numbers of cycles: 1-10
Cycle wait mode: Time, Temp
C->D Delay: 1-240min
D->C Delay: 1-240min
C->D temperature: 20-70°C / 68-158°F
D->C temperature: 20-70°C / 68-158°F
Specific for LiPo
Charge mode: CC-CV
Cells: 1-4
Charge end voltage/cell: 4,2V
Limits of discharge current: 1-2 cells - max 20,0A
Limits of discharge current: 3 cells - max 13,5A
Limits of discharge current: 4 cells - max 10,0A
Cutoff voltage/cell: 2,7-3,7V
Specific for Lixx
Charge mode: CC-CV
Cells: 1-4
Charge end voltage/cell: 3,3-4,3V
Limits of discharge current: 1-2 cells - max 20,0A
Limits of discharge current: 3 cells - max 13,5A
Limits of discharge current: 4 cells - max 10,0A
Cutoff voltage/cell: 2,0-3,7V
Specific for PB
Charge mode: CC-CV
Cells: 1-6
Charge end voltage/cell: 2,35V
Limits of discharge current: 1-3 Zellen - max 20,0A
Limits of discharge current: 4 Zellen - max 15,0A
Limits of discharge current: 5 Zellen - max 12,0A
Limits of discharge current: 6 Zellen - max 10,0A
Cutoff voltage/cell: 1,8-2,3V
Motor break-in
Run Time: 1min - 23h 59min
Voltage: 0,1-8,0V
Current: max 12,0A
Glow-plug
Voltage: 0,1-2,5V
Current: max 12,0A
Tire warmers
Temperature: 45-75°C / 113-167°F
Voltage: 13,5V
Current: max 12,0A
